On Chip Memory Controller
Video Input Port
Display
Subsystem
3 LCD
HDMI 1.4a
1080p
Blend/Scale/
Convert
2 PCIe
10 UART
4 McSPI
QSPI
8 McASP
Serial IO
5 I2C
SATA
NAND/NOR
4 MMC
/SD
DMM
Storage IO
USB3
3
USB2
2 DCAN
Video AccelerationPac
IVA HD 1080p Video, VPE
Graphics AccelerationPac
BB2D
GC320
3D GPU SGX544
3 PWM/CAP/QEP
GPIO
Security AccelerationPac
2 AES, 2 SHA2MD5, DES3DES, FPKA, RNG
2x Programmable Real-Time
Unit Subsystems (PRU-ICSS)
4x 200MHz PRU Execution units
EtherCAT, PROFINET ,EtherNET/IP,
PROFIBUS, POWERLINK, SERCOS 3
GbE 2-port switch
w/1588
MII/RMIIRGMII/
SGMII
CryptoDMA
13 mailbox
RTC
Secure WDT
WDT
Spinlock
EDMA
System Services
16 Timer
KBD
1MB
Shared L2
ARM
Cortex-A15
32K/32K L1
32KB
Shared L1
1 x 24-bit
Benefits
Optimized single-core version of AM572x
5,250 ARM Cortex-A15 DMIPS
Layout and Software compatible w/ AM572x
Same great peripheral set
Sample Applications
Industrial Drives
Human Machine Interface (HMI)
Networking
Navigation & Consumer
Aviation/Military/Safety
Key Features
1.5GHz ARM Cortex-A15, Dual 213MHz ARM Cortex-M4; 750MHz C66x DSP
1080p Video Decode/Encode
3D and 2D Graphics Acceleration
2 x Programmable Real-time Unit (PRU)/Industrial Communications Subsystems
32-bit EMIF w/ ECC Support
Power Estimates
Total Power: 1.6-3.6W
Idle Power: 200-300mW
Package: 23x23, 0.8mm w/VCA
Availability:
Samples: 4Q14
Production: mid-2015
512KB L3 Shared RAM w/ECC
Not available in AM5716
ARM
Cortex-A15
32K/32K L1
ARM
Cortex-A15
32K/32K L1
32KB L1
64KB RAM
Benefits
Sitara’s highest performance ARM device w/DSP accelerators
10,500 ARM Cortex-A15 DMIPS
Upgraded graphics performance with HD Video support
Sample Applications
Human Machine Interface (HMI)
Digital Signage
High-end Navigation
High-end Consumer
Industrial PC
Key Features
Dual 1.5GHz Cortex-A15s, 213MHz M4s, and 700MHz C66x DSPs
1080p Video Decode/Encode
3D (x2) and 2D acceleration
1 x Video Input Port (4 inputs)
Multiple display subsystem
2 x Programmable Real-time Unit (PRU)/Industrial Communications Subsystems
Power Estimates
Typical Power: 2.5-4W
Idle Power: 200-300mW
Package: 23x23, 760 pin, 0.8mm w/VCA
Availability:
Samples: 3Q14
EVM: 3Q14
Production 4Q14
32b DDR3/3L w/ECC
Video AccelerationPac
IVA HD 1080p Video, VPE
CryptoDMA
13 mailbox
RTC
Secure WDT
WDT
Spinlock
EDMA
16 Timer
KBD
2.5MB L3 Shared RAM w/ECC
Not available in AM5726
Pin muxing may limit peripheral availability
Security AccelerationPac
2 AES, 2 SHA2MD5, DES3DES, FPKA, RNG
2 x PRU
Industrial
Communication Subsystem EtherCAT®,PROFINET®, EtherNET/IP™, PROFIBUS, POWERLINK, SERCOS 3
