Слайд 1
Текст слайда:

Wireless LANs

Configuring Cisco WLAN Clients


Слайд 2
Текст слайда:

Cisco 802.11a/b/g WLAN Client Adapters

802.11a/b/g dual-band client adapters
Supports all three current standards
54 Mbps in 2.4 and 5 GHz bands
802.11b support provides investment protection
CardBus or PCI card
Supported operating systems
Windows 2000 and Windows XP
Utilities
ADU: Aironet Desktop Utility
ACM: Aironet Client Monitor
ACAU: Aironet Client Administration Utility


Слайд 3
Текст слайда:

Client Adapter Installation Wizard

Requires a forced reboot at the completion of the install (prompts in the beginning as a warning).
Protection to ensure that machine is left in a stable state.
Shows multiple status screens.
Drivers, ADU, firmware, LEAP, and so on.
Card must be inserted at the beginning of the setup and must be identified by the computer as new hardware. (If it is not identified as new hardware, reboot the laptop.)


Слайд 4
Текст слайда:

Cisco ADU Installation

Multiple options for installation


Слайд 5
Текст слайда:

Install Cisco Aironet Site Survey Utility



Слайд 6
Текст слайда:

Choose Configuration Tool


Слайд 7
Текст слайда:

ADU Main Screen

Shows client IP address



Слайд 8
Текст слайда:

Advanced Status Information



Слайд 9
Текст слайда:

ADU: Main Profile Screen

Multiple profiles
Auto profile selection
Can scan for access point SSIDs




Слайд 10
Текст слайда:

ADU: General Settings

Create/modify profile



Слайд 11
Текст слайда:

ADU: Security Settings

Wi-Fi Protected Access (WPA)/WPA2 support
Advanced Encryption Standard (AES) and Extensible Authentication Protocol-Flexible Authentication via Secure Tunneling (EAP-FAST) supported


Слайд 12
Текст слайда:

ADU: Advanced Settings

Selectively choose wireless modes to decrease association time.


Слайд 13
Текст слайда:

ADU Diagnostics: Advanced Statistics

Used predominately during troubleshooting


Слайд 14
Текст слайда:

ADU Diagnostics: Adapter Information

Driver version


Adapter MAC address



Слайд 15
Текст слайда:

ADU Troubleshooting


Слайд 16
Текст слайда:

Cisco Aironet System Tray Icon


Слайд 17
Текст слайда:

Cisco Aironet Site Survey Utility


Слайд 18
Текст слайда:

Cisco Aironet Site Survey Utility (Cont.)


Слайд 19
Текст слайда:

Windows XP WLAN Configuration


Слайд 20
Текст слайда:

Comparison of Windows XP and Cisco ADU


Слайд 21
Текст слайда:

Aironet Client Administration Utility (ACAU)

Creates file with profiles and settings
Profiles imported during the installation of ADU and firmware
For AIR-CB21AG and AIR-PI21AG
Installs across network
Encrypted setup files
Windows 2000 and Windows XP only


Слайд 22
Текст слайда:

Aironet Configuration Administration Utility

Easy binary configurations for security and utility


Слайд 23
Текст слайда:

Cisco Wireless IP Phone

For workers who need to communicate while moving about their workplace or campus
Same features as Cisco wired IP Phones
Graphical, menu-driven user interface
Multiline appearance (up to six extensions)
Phone book with speed dials
LEAP security
Auto VLAN configuration and Cisco CallManager registration










Слайд 24
Текст слайда:

Cisco Compatible Extensions

No-cost licensing of technology for use in WLAN adapters and devices
Independent testing to ensure interoperability with Cisco infrastructure
Marketing of compliant products by Cisco and product suppliers under “Cisco Compatible” brand


Слайд 25
Текст слайда:

Cisco Compatible Extensions (Cont.)

Cisco Compatible client devices
Features
Assured compatibility with 300+ devices
Standards-based
Enhanced security, mobility, and performance
Benefits
Accelerates innovation
Supports diverse enterprise applications
Ensures multivendor interoperability

http://www.cisco.com/go/ciscocompatible/wireless


Слайд 26
Текст слайда:

Cisco Compatible Extensions Features


Слайд 27
Текст слайда:

Cisco Compatible Extensions Program

Develops interoperability with semiconductor and client vendors
Provides additional functionality and performance improvement while working with Cisco access points and Cisco wireless infrastructure
Objective: The Cisco Compatible Extensions program provides customers with a broad range of WLAN client devices that have tested interoperability with Cisco Aironet innovations.
Phase 1:
Specification: Cisco provides specification to WLAN silicon providers.
Phase 2:
Interoperability test: Devices are tested by approved third-party vendor for the specification.
Phase 3:
Compatibility: Approved products are marketed.


Слайд 28
Текст слайда:

Summary

The installation wizard for the Cisco 802.11a/b/g WLAN client adapter installs driver and utilities.
The Cisco 802.11a/b/g client adapter is configured via Cisco ADU.
Cisco ADU can be used for troubleshooting the client adapter.
The Cisco Aironet Site Survey Utility provides information about available WLANs.
Cisco ADU provides more features than Windows XP for the Cisco client adapter configuration.
Cisco ACAU provides preconfiguration of WLAN profiles for software distribution.
The Cisco Wireless IP Phone provides integration of IP telephony into WLANs.
The Cisco Compatible Extensions program enhances WLAN features for WLAN adapters from multiple vendors.
